STANDARD FEATURES

  • >Cold rolled steel sheets conforming to ASTM A366.
  • Sheet Thickness: 1.5 mm.
  • Jamb depth 150 mm.
  • Welded corners with temporary bottom spreader bars.
  • 4.2 mm thick steel hinge reinforcement For template mortise hinges. 4.5" (114.3 mm) height.
  • 3 silencers (Rubber Mutes) @ single leaf frame lock jamb. OR 2 silencers (Rubber Mutes) @ double leaves frame head.
  • Finished in Epoxy Primer Paint, factory applied.

OPTIONS

  • Fire rated •Label up to 3 hours.
  • Bullet resistant •Label up to level 4.
  • Hot - dipped galvanized steel sheets conforming to ASTM A526 or A642 & A525.
  • Sheet thickness:
    • Level (1), Standard duty, 1.2 mm thick
    • Level (3), Extra heavy duty, 2.0 mm thick
    • Level (4), Maximum duty, 2.5mm thick
  • Jamb Depth up to 350 mm.
  • Perimeter weather & cold smoke gasket @CFWK profiles.
  • Electric staration
  • Four Sided for Access Panels.
